How NetFlow Helps Network Engineers

The ability to characterize IP traffic and understand how and where it flows is critical for assuring network availability, performance, and security. A NetFlow analyzer is a tool deployed to perform monitoring, troubleshooting and in-depth inspection, interpretation, and synthesis of traffic flow data.  Analyzing NetFlow facilitates more accurate capacity planning and ensures that resources are used appropriately in support of organizational goals. It helps network operators to determine where to apply Quality of Service (QoS) policies as well as how to optimize resource usage, and it plays a vital role in network security to detect Distributed Denial-of-Service (DDoS) attacks and other undesirable network events and activity.

Overcoming Common Network Challenges with a NetFlow Analyzer

A NetFlow analyzer offers insight to overcome many common challenges encountered by network operators, managers, and engineers including:

  • Monitoring major contributors of network traffic:  Network engineers can easily see top talkers and listeners on the network.
  • Understanding application traffic and its network impact:  An example is identifying unusual application network loads such as video content or large file transfers.  NetFlow statistics can also be used to measure how application and policy changes affect costly WAN traffic.
  • Optimizing Internet peering relationships:  Organizations operating BGP peerings to maintain multi-homed connectivity to the Internet can utilize NetFlow data fused with BGP routing data to perform sophisticated peering analysis and optimize their peering arrangements.  This can help to improve service quality, reduce peering costs, or even uncover new revenue opportunities as a result of usage pattern analysis.
  • Troubleshooting and understanding network pain points:  NetFlow analysis can be used to diagnose slow network performance, recognize bandwidth hogs or misconfigurations, and characterize bandwidth utilization quickly via the intrinsic representation of traffic totals and traffic details.
  • Detecting unauthorized WAN traffic:  By analyzing NetFlow, it becomes possible to avoid costly upgrades to expensive WAN services by identifying the applications causing congestion, verifying legitimacy, and adjusting delivery policies to mitigate any adverse impact on higher-value concurrent traffic streams.
  • DDoS and anomaly detection:  NetFlow can also be used for detection of DoS/DDoS and other types of network behavior anomalies.
  • Validating QoS parameters:  Because NetFlow includes all packet priority markings, it can be used to confirm that appropriate bandwidth has been allocated to each Class of Service (CoS) and that no CoS is over or under-subscribed.

Various organizations such as network operations, engineering, planning, architecture, and security can use NetFlow analyzers as a primary source of intelligence.  Proper use of NetFlow analysis can reduce the number of hardware and software technologies needed to manage networks.  This reduces network administration costs and enhances cross-organizational collaboration and communications and help cross-functional teams get the most out of network investments.



NetFlow analysis supports multiple use case



Network Analyzers & Planning

NetFlow data provides key information for sophisticated analysis to optimize both strategic network planning (e.g. who to peer with, backbone upgrade planning, routing policy planning) as well as tactical network engineering decisions (e.g. adding additional VIPs to routers, upgrading link capacity) – minimizing the total cost of network operations while maximizing network performance, capacity and reliability.

Network Monitoring

NetFlow data enables extensive, near real-time network monitoring capabilities. Flow-based analysis techniques may be utilized to visualize traffic patterns associated with individual routers and switches as well as on a network-wide basis (providing aggregate traffic or application based views) to provide proactive problem detection, efficient troubleshooting, and rapid problem resolution. Analysis of NetFlow can be used as a basis for real-time alerting, improving network operators’ ability to react quickly and accurately to any major service disruptions as well as get early warning indicators of potential performance and service quality degradations that warrant proactive intervention.

Application Monitoring and Profiling

NetFlow data enables network managers to gain a detailed, time-based, view of application usage over the network. Any common NetFlow type can be used to recognize applications by port/protocol, and some of the more advanced extensions to NetFlow (via sFlow or v9/IPFIX templates) such as Cisco’s Application Visibility and Control (AVC) solution can document much greater application detail. Content and service providers may utilize this information to plan and allocate network and application resources (e.g. web server sizing and location) to responsively meet customer demands.  Enterprises can use these same insights to understand application dependencies and resource consumption.

User Monitoring and Profiling

NetFlow analyzer data enables network operators to gain detailed understanding of customer/user utilization of network and application resources. This information may then be utilized to efficiently plan and allocate access, backbone and application resources as well as to detect and resolve potential security and policy violations.
